Ventilator - Standard- On Rent

Description: Patient Age Group Adult, Pediatric Tidal Volume 50 ml to 2500 ml Ventilation Modes Volume Controlled: Assisted/Control (A/C), SIMV, CPAP Pressure Controlled: Assisted/Control (A/C), SIMV Apnea: CPAP Non-invasive: Spont.; Spont./T Respiratory Rate 1 to 80 bpm Controls Trigger Pressure Trigger: -20 to -0.1 cm H₂0, Inspiratory Flow Trigger: 0.5 to 20 LPM Base Flow 3 LPM above flow sensitivity (with flow triggering), Expiratory Flow Trigger: 10 to 45% of peak flow Settings Inspiratory Pressure 5 to 100 cm H₂0 PEEP/CPAP 0 to 35 cm H₂0 Inspiratory time 0.1 to 9.9 seconds Inspiratory flow 3 to 140 LPM (Compensated) Monitoring Peak Inspiratory Pressure -20 to 130 cm H₂0 (On Screen) Inhaled/ Exhaled Tidal Volume 0 to 9999 ml RSBI 0 to 500 (f/Vt) Performance Display unit size Color 10.4 Touch Screen Input / Output ports RS-232 Output and Remote Communication I:E Ratio 9.9:1 to 1:99 Minute volume Spontaneous: 0 to 99.0 LPM, Expiratory: 0 to 60 LPM Operating Data Dimensions 40.5 x 35.6 x 61 cm Weight 30 kg / 39 kg (w/Battery) Options 0 to 110% Oxygen Delivered Optional Alarm Apnea alarm time 10 to 60 seconds Audible Alarm Volume Adjustable 54 to 77 db (complies with EN475 Standard) Alarm Silence 120 seconds High Inspiratory Pressure 10 to 105 cm H₂0 Low Inspiratory Pressure 3 to 105 cm H₂0 High Respiratory Rate 0 to 150 bpm Expiratory Tidal Volume Low Mandatory: 0 ml to 2500 ml, Low Spontaneous: 0 ml to 2500 ml Additional Details Waveform display Flow Descending Ramp, Square Expiratory Pressure Parameters & Ranges: -20 to 130 cm H₂0 (On Screen), Calculated Values: -20 to 120 cm H20 (On Screen) Leakage Compensation Up to 60 LPM Expiratory Percent O₂ 21 to 100% Apnea Rate 1 to 80 bpm Volume Controlled Ventilation Plateau 0 to 2.0 seconds Spontaneous Flow Up to 200 LPM (Uncompensated) PSV Pressure 0 to 100 cm H₂0 EPAP/CPAP Pressure 2 to 25 cm H₂0 IPAP Pressure 2 to 35 cm H₂0 Patient Leak 0 to 140 LPM Average Pressure -20 to 120 cm H₂0 (On Screen) Plateau Pressure -20 to 130 cm H₂0 (On Screen) Auto PEEP -20 to 120 cm H₂0 Features Intuitive Menu Structure Upgradeable System Software Standard Simple Breathing Circuit And Filters Full Graphics Scalars, Loops And Trending Universal Power Supply Plus Battery Back-up Mounting Options (Carts And Wall Mount) Three-step Setting Change Process Prioritized Alarms No Need For Wall Air Or Compressor Applications Emergency Care & ICU Product Description The flexible Esprit Ventilator combines sophisticated design with easy-to-use features. This dual-platform (invasive and non-invasive) microprocessor driven ventilator offers a full range of modes and breath types in Volume Control Ventilation (VCV), Pressure Control Ventilation (PCV) and Non-Invasive Positive Pressure Ventilation (NPPV) Esprit incorporates a fast response, high performance blower that removes the need for wall air source gas. Respironics exclusive Auto-TRAK ensures correct sensing of patient effort and leak compensation. The Esprit features a full array of graphics to rapidly assess patient condition. Scalars, Loops, Trends and Respiratory Mechanics guide therapy with immediate, real time feedback concerning patient response to ventilator settings. This allows fast optimization specific to each individual patient. An optional communication package provides 2-way communication between Esprit and the NICO2 Cardiopulmonary Monitor with information displayed directly in Esprit trend graphs. Full color, touch screen user interface is easy to read and operate. Intuitive menu structure provides a fast learning curve and easy to find settings. Simple patient breathing circuit enables fast and effective turn around between patients. Integrated self diagnosis screens accommodate rapid operation verification. Esprit is a full featured, dual platform intensive care ventilator well suited for all patient populations and patient needs - neonate to adult.
